HIGH PRECISION SELF CENTERING STEADY REST OMSR-E MODEL

Product Categories

Omatei Mechanical And Electrical Equipment Co., Ltd

Trust Seal

Verified Supplier

Credit Check

Supplier Assessment

Contact Now

Brand Name : NTH

Model Number : OMSR-E1, OMSR-E2, OMSR-E3, OMSR-E4,

Place of Origin : CHINA

MOQ : 1set

Payment Terms : Western Union, T/T

Supply Ability : 1000sets/M

Delivery Time : 3 work days

Packaging Details : Good and firm package is suitable for sea and air shipping

Price : Negotiation

Product name : HIGH PRECISION SELF CENTERING STEADY REST OMSR-E MODEL

Material : Cast steel

Usage : Fixture/Gripping/Prop up

Feature : Creative design/Wide clamping/High precision

Size : Refer to the specification

Service : Cylinders differing from standard available on request

Contact Now

HIGH PRECISION SELF CENTERING STEADY REST OMSR-E MODEL

APPLICATION/ADVANTAGES

Support of shaft type workpieces on grinding machines

Particularly suitable for the machining of crankshafts and camshafts

Rapid set up of the Steady Rest to the grinding center with the fine adjustment

Suitable for Follow down grinding

HIGH PRECISION SELF CENTERING STEADY REST OMSR-E MODEL

NTH-OMSR Model Spec	OMSR-E1	OMSR-E2	OMSR-E3	OMSR-E4
D1(mm)	48	70	92	114
D2(mm)	70	92	114	136
D3	M16x5	M16x5	M16x5	M16x5
L1(mm)	90	90	90	90
L2(mm)	263.4	263.4	263.4	263.4
L3(mm)	29	29	29	29
L4(mm)	201.7	201.7	201.7	201.7
L5(mm)	595	595	595	595
L6(mm)	243.7	243.7	243.7	243.7
L7(mm)	310	310	310	310
L8(mm)	71	71	71	71
L9(mm)	138.5	138.5	138.5	138.5
L10(mm)	235.9	235.9	235.9	235.9
A1(mm)	21.2	21.2	21.2	21.2
A2(mm)	44.1	44.1	44.1	44.1
A3(mm)	129.5	129.5	129.5	129.5
B1(mm)	65.3	65.3	65.3	65.3
B2(mm)	64.2	64.2	64.2	64.2
Work pressure Max. (bar)	35	35	35	35
Work pressure (bar)	10/30	10/30	10/30	10/30
Repeatability accuracy (mm)	±0.002	±0.002	±0.002	±0.002
Weight(KG)	76.4	76.4	76.4	76.4

Cylinders differing from standard available on request,Subject to technical changes.

Product Tags:

hydraulic self centering steady rest
